Typology
Next to iTop's topology elements, TeemIp proposes different typology classes to predefine the type of a few IP objects.
Like all topology elements, these IP ones are managed through the Typology configuration menu of the Data Administration module.
IP Block Type
IP Block Types will allow administrators to define the main usage that an IP Block can have: user space, data centre space, interconnections… Name of type being defined through a free text attribute, administrators can really create what suits their needs best.
IP Block Type Properties
| Name | Type | Mandatory? |
|---|---|---|
| Name | Alphanumeric string | Yes |
| Description | Multiline character string | No |
Updating an IP Block Type
In the Typology configuration menu of the Data administration module, under the IP space typology configuration chapter, click on the IP Block Type badge to list all IP Address Usages and select the one you'd like to edit.
IP Range Usage
IP Range Usages will allow administrators to document the usage made of IP ranges in their environment: Printers, Consoles, DHCP pools… Name of usage being defined through a free text attribute, administrator can really create what suits their needs best.
IP Range Usage Properties
| Name | Type | Mandatory? |
|---|---|---|
| Organization | Foreign key to a(n) Organization | Yes |
| Name | Alphanumeric string | Yes |
| Description | Multiline character string | No |
Creating a new IP Range Usage
In the Typology configuration menu of the Data administration module, click on Create a new IP Range Usage to display the creation form.
IP Address Usage
IP Address Usages will allow administrators to define the role that an IP can take in their environment: standard usage like Printer or Gateway IP or more technical one like HSRP or High Availability. Name of usage being defined through a free text attribute, administrators can really create what suits their needs best.
IP Address Usage Properties
| Name | Type | Mandatory? |
|---|---|---|
| Organization | Foreign key to a(n) Organization | Yes |
| Name | Alphanumeric string | Yes |
| Description | Multiline character string | No |
Updating an IP Address Usage
In the Typology configuration menu of the Data administration module, under the IP space typology configuration chapter, click on the IP Address Usage badge to list all IP Address Usages and select the one you'd like to edit.
WAN Link Type
WAN Link Types allow administrators to predefine the type of WAN links used.
WAN Link Type Properties
| Name | Type | Mandatory? |
|---|---|---|
| Name | Alphanumeric string | Yes |
| Description | Multiline character string | No |
Creating a new WAN Link Type
In the Typology configuration menu of the Data administration module, under the Network typology configuration chapter, click on “Create a new WAN Link Type” to display the creation form.
Other typologies
Other typological elements are brought by other extensions and are documented in their dedicated wiki:
- DHCP class and DHCP subclass belong to the TeemIp DHCP Management extensions,
- Network Device Type is defined in iTop datamodel,
- Interface Speed, Layer 2 Protocol and Interface Connector are brought by TeemIp Network Management Extended
- Cable Type and Cable Category come with the TeemIp Cable Management
